Glass Bottle Internal Pressure Tester
The instrument measures the internal pressure resistance of glass bottles and containers using pass, increasing-pressure, and destructive test modes. It is intended for glass bottles, infusion bottles, and wine bottles under GB/T 4546-2008 and ISO 7458:1989.
- Model
- BLP-10
- Category
- Glass Testing
Product Description
The instrument is designed according to GB/T 4546-2008 and ISO 7458:1989 for glass bottles, glass infusion bottles, and wine bottles. It displays internal pressure in real time and supports pass, increasing-pressure, and destructive tests.
Method A applies uniform internal pressure and holds it for 60 s; a bottle that does not break passes. Method B increases pressure at a specified constant rate to Pr = 1.38P60 + 0.1783, then releases it without a hold. The system displays hold pressure, destructive peak pressure, P60, and test count, prints results, uses water as the pressurizing medium, and completes one bottle test in no more than 8 s.
Technical Specifications
| Parameter | Specification |
|---|---|
| Sensor pressure range | 0–6 MPa; safety overload 7.2 MPa |
| Maximum set test pressure | 6.00 MPa |
| Display accuracy | 0.001 MPa |
| Operating temperature | 5–40 °C |
| Linear pressure increase rate | 0.58 ± 0.1 MPa/s (4 ± 1 bar/s) |
| Pressurizing medium | Water |
| Power supply | 220 V, 50 Hz; rated power 0.6 kW |
| Display output | LED four-window display for real-time values, set values, P60 values, and test count |
