Dynamic Elastic Modulus Tester
The DTM-II Dynamic Elastic Modulus Tester determines dynamic elastic modulus from material resonance frequency measured by impact excitation and frequency analysis. It is used for concrete, carbon, glass, brick, plastic, metal, and other nonmetallic materials in construction and related laboratories.
- Model
- DTM-II-
- Category
- Mechanical Testing
Product Description
The DTM-II measures basic resonance frequency by impacting the specimen and sensing vibration with an accelerometer. Fast Fourier Transform identifies the resonance peaks; the spectrum is stored and displayed on a computer, and the system automatically calculates maximum amplitude without manual frequency scanning. Computer connection supports automated test analysis.
The instrument can measure resonance frequency and elastic modulus for concrete, carbon, glass, stone slabs, brick, plastics, metals, and other nonmetallic materials. Resonance testing supports repeated measurements on one specimen during concrete freeze–thaw durability studies and can also measure shear modulus, Poisson's ratio, damping, and internal friction. Referenced methods include ASTM C215, ASTM C666, SL 352-2006, DL/T 5150-2001, and DL/T 536-2006.
Technical Specifications
| Parameter | Specification |
|---|---|
| Frequency range | 10 Hz–20 kHz |
| Frequency resolution | 1 Hz |
| Sampling-rate options | 10 kHz, 20 kHz, 40 kHz, or 80 kHz |
| Spectrum resolution | 4.9–78.1 Hz |
| Bias-level output | 9.2 V |
| Accelerometer sensitivity | 9.60 mV/g (0.979 mV/(m/s²)) |
| Maximum exciter force | 20 N |
| Specimen dimensions | 150 × 150 × 400 mm, rectangular prism |
| Operating temperature | Room temperature–40 °C |
| Dynamic elastic modulus resolution | 0.05 GPa |
| Dynamic elastic modulus accuracy | 0.1 GPa |
| Damping or internal friction | 10⁻⁵–0.1 |
