SQW-II-14 High-Temperature Materials Test System
SQW-II-14 is a high-temperature materials test system for thermal expansion, high-temperature compressive strength, expansion force, deformation under constant load, residual strength, and room-temperature compressive strength. It is intended for inorganic nonmetallic materials and molding mixtures, with normal furnace operation to 1,350 °C and short-term operation to 1,400 °C.
- Model
- SQW-II-14
- Category
- Mechanical Testing
Product Description
The system supports high-temperature and room-temperature mechanical and dimensional tests for inorganic nonmetallic materials and molding mixtures, including simulation of molten-metal pouring into a mold. Test modes include thermal expansion, high-temperature and room-temperature compressive strength, expansion force, constant-load thermal deformation, and residual strength.
The system incorporates a silicon-carbide-tube high-temperature furnace with a 50 mm chamber diameter and a 2.5 kW rating. Loading speed is manually adjustable, and the heating program supports user-set constant-rate operation with two program segments.
Ordering information: This page is a configuration overview; obtain a verified model-specific datasheet for the load range, deformation travel, force and deformation accuracy, and complete specimen drawing before selection. Specify the required test modes, specimen geometry, heating program, furnace configuration, control-cabinet form, and site electrical supply when requesting a quotation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Test modes | Thermal expansion; high-temperature compressive strength; expansion force; constant-load thermal deformation; residual strength; room-temperature compressive strength |
| Heating temperature | Room temperature to 1,350 °C; 1,400 °C short-term |
| Specimen geometry | Conical specimen, 30 mm base diameter × 50 mm high |
| Deformation display resolution | 0.01 mm |
| Heating rate | User-set constant-rate, two-segment programmable control |
| Furnace type | Silicon-carbide-tube high-temperature furnace |
| Furnace chamber diameter | Ø50 mm |
| High-temperature furnace power | 2.5 kW |
| Loading displacement rate | 0.8–8 mm/min, manually adjustable |
| Instrument dimensions (L × W × H) | 720 × 500 × 1,644 mm |
| Control cabinet | Tabletop or floor-standing |
| Total mass | 500 kg |
| Power consumption | <3 kW |
| Ambient temperature | 0–40 °C |
| Relative humidity | <85% RH |
| Power supply | Single-phase AC 220 V ±10%; 50 Hz |
| Site conditions | No strong magnetic interference, strong vibration, or corrosive gas; reliable protective grounding |
