SJY-II-14/17 High-Temperature Imaging Analyzer
SJY-II-14/17 is a high-temperature transmission-imaging analyzer for sintering-point temperature, refractoriness, and surface contact angle. It is used with molding sands, mixtures, refractory materials, ceramic raw materials, and metallic materials.
- Model
- SJY-II-14/17
- Category
- Refractory Testing
Product Description
The transmission-imaging system displays specimen shrinkage, expansion, and surface contact angle with the corresponding temperature. It supports visual observation and image recording for materials research, foundry, ceramic, and glass applications.
Ordering information: Specify the furnace-temperature rating, specimen geometry, image-analysis functions, and control configuration when requesting a quotation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Maximum heating temperature | 1,400 °C or 1,700 °C |
| Furnace chamber diameter | 30 mm |
| Temperature-control accuracy | ±1 °C |
| Image magnification | 8–9× |
| CCD camera resolution | ≥3 megapixels |
| Power supply | 220 V ±10%; 2.5 kW |
| Computer interface | Standard interface; computer-controlled testing |
| Image-processing functions | Image storage and printing; contact-angle analysis; shrinkage/expansion analysis; historical-data query |
