Guarded Hot Plate Thermal Conductivity Analyzer
The DRX-I-PB（PC） measures the thermal conductivity of plastics, glass, fibers, and foams by the guarded hot plate method. It is intended for material-testing, research, quality-control, and higher-education laboratories and can be configured with water-bath or DRX-I-PC heating and optional thermal-resistance or heat-flow-meter setups.
- Model
- DRX-I-PB（PC）
- Category
- Thermal Conductivity & Diffusivity
Product Description
The guarded hot plate configuration covers plastics, glass, fibers, and foams. GB/T 3392-82 and GB/T 3139-2005 are referenced, with GB/T 10801.1 and GB/T 10801.2 also listed for insulation-foam materials. Optional thermal-resistance and heat-flow-meter configurations are associated with GB/T 10295-1988, ISO/DIS 8301, and EN 12667; verify the applicable method, standard, and hardware for the selected variant.
The water-bath configuration has an 80 °C hot plate and a cold plate cooled below room temperature; the DRX-I-PC configuration has a heater-controlled hot plate below 300 °C and optional cold-side cooling to −20 °C. The DRX-I-PC configuration can be fitted for single- or dual-specimen testing, and specimen options are 200 × 200 mm with 5–20 mm thickness or 300 × 300 mm with 5–50 mm thickness. The page is a configuration overview; obtain a verified model-specific datasheet before selecting the test method, variant, and specimen option.
Technical Specifications
| Parameter | Specification |
|---|---|
| Hot-plate temperature (water-bath configuration) | 80 °C; heated thermostatic water bath |
| Cold-plate temperature (water-bath configuration) | Below room temperature; cooled by a thermostatic water bath |
| DRX-I-PC hot-plate temperature | Below 300 °C; heater-controlled |
| DRX-I-PC cold-plate temperature | Below room temperature; optional cooling down to −20 °C |
| Metered heating power | 35 W |
| Specimen dimensions (option 1) | 200 × 200 mm; thickness 5–20 mm |
| Specimen dimensions (option 2) | 300 × 300 mm; thickness 5–50 mm |
| Referenced standards | GB/T 3392-82; GB/T 3139-2005; GB/T 10801.1; GB/T 10801.2 |
| Thermal conductivity range | 0.015–2 W/(m·K) |
